Marine Mooring Wharf Towing Equipment Triple Quick Release Mooring Three Hook
Description
Quick release mooring hooks is widely used due to its safety, reliability, feature of laborsaving and shortcut, etc, composed by stranded cable structure and release mooring structure.
Our Quick Release Mooring Hook has the advantages of reasonable structure, reliable quality and safe use.We provide four types of quick release mooring hooks: single hook, double hook, triple hook, quadruple-hook; the double hook and triple hook are the most widely-ranging used.
Main Technical Performance
1.Hook’s motion range: lateral horizontal movement within the range of 90 degrees , 45 degrees vertical elevation
2.Handle Operation Force <150N
3.The fore-end of anchor hook is equipped with elastic cushion, which prevent the collision between the hook and frame
4.Motor: three phase380V 50HZ or 400V 60HZ,Optional explosion-proof or non-explosion proof.
5.Brake: short circuit protection, over load protection
6.Optional Level of Protection: IP55,IP56,IP65,IP66
7.Manual release, pneumatic or hydraulic release
Specification
1.Number of Hooks: 3 Hooks
2.Safe Working Load: 400kN to 1500kN
3.Weight exclude Capstan: 1200kg to 3586kg
4.Operating force by handle: < 150N
5.Swing angle of hook body in horizontal: 45~900
6.Swing angle of hook body in vertical: 450
7.Puling speed of electric capstan: 18~25m/min
8.Pull of electric capstan: 10KN~30KN
9.Working diameter of capstan: 250mm
| SWL (KN) | Weight
(kg) | A | B | BB | C | D | E | EE | F | G | H | K | R | X |
| 400 | 304 | 668 | 600 | 600 | 225 | 54 | 225 | 225 | 35 | 370 | 1268 | 96 | 75 | 4*M48 |
| 600 | 512 | 873 | 650 | 650 | 235 | 54 | 235 | 200 | 45 | 407 | 1523 | 130 | 90 | 6*M48 |
| 750 | 587 | 923 | 650 | 650 | 225 | 62 | 225 | 200 | 45 | 417 | 1573 | 130 | 100 | 6*M56 |
| 1000 | 792 | 1014 | 700 | 650 | 225 | 62 | 250 | 200 | 50 | 447 | 1714 | 150 | 100 | 6*M56 |
| 1250 | 887 | 1085 | 700 | 650 | 225 | 70 | 250 | 200 | 55 | 479 | 1785 | 150 | 100 | 6*M64 |
| 1500 | 1253 | 1255 | 700 | 650 | 225 | 78 | 250 | 195 | 55 | 499 | 1955 | 150 | 100 | 6*M72
|
We offers kinds of marine towing hook for your option, please take the bellow as reference:
| 1.Spring Towing Hook |
| 2.Disc Towing Hook |
| 3.Quick Release Hook |
| 4.Pelican Hook |
| 5.Marine Harbour Towing Hook |
| 6.Manual Release Spring Towing Hook |
| 7.Pneumatic Release Spring Towing Hook |
| 8.Manual Release Springless Towing Hook |
| 9.Pneumatic Release Disc Towing Hook |
| 10.Hydraulic Release Disc Towing Hook |
| 11.Hydraulic Release Harbour Towing Hook |
| 12.Single Quick Release Mooring Hook |
| 13.Double Quick Release Mooring Hook |
| 14.Triple Quick Release Mooring Hook |
| 15.Quadruple Quick Release Mooring Hook |
About US
Weitong Marine focus on developing and offering the most competetive marine products for worldwide clients with best service:
1. Quality Assurance & Inspection
We guarantee the quality,not just because we have a complete rigorous management, production and inspection processes to control the quality and avoid detail mistake, but also we attach much importance to customers’ satisfactory of product quality. What’s more, Mill Test Certificate can be provided for general products, and most of our products are approved by CCS, ABS, DNV, BV, NKK, KR, LR, GL, RINA etc.
2. Efficiency
Your request is promised to be reponsed within1-12 hours. Our experienced sales team get technical support from our engineer team to ensure swift offer and good communication.
3.On Time Delivery
We have rigorous production schedule and professional follow-up process to control the production time. Clients will be informed about the production process in time. Besides, we cooperate with reliable logistic partners to assure the goods to be delivered to you punctually.
4. Customization
If you need customization service, our experienced engineers are able to design the product as per your request or application.
5. Product Range
All marine equipment, accessories and technique solution can be offered.
6.After sales service
After shipping, we keep tracking the shipment, and once goods arrived, we will positively contact client for feedback.
We always insist on the values of “customer-oriented, integrity first” in global trade business. Whenever you need inquiry or help, you can always turn to Weitong Marine, we are always available to reply with answer or provide help over the phone, by email or other.
Should you have any comment or inquiry, please feel free to contact us for more details
Ms kate
Tel: +86-756-8169003
Phone: +86-13923317268
Website: www.weitongmarine.com
sales@weitongmarine.com
Ohter Product Photos
