Product Description
AC-14 HHP Type Offshore Aquaculture Marine Anchor Stockless Boat Anchor
AC 14 HighHolding Power Anchor is developed from stockless anchor.The AC-14 HHP Anchor is suitable for all kinds of seabed (Mud, Soil, Sand, Sandstone, etc.), dig into the seabed quickly and excellent stability, holding-power-to-weight is up to 14. AC-14 HHP Anchor used for shipping or agriculture industry.
Material: Casting Steel ZG200-400C
Weight: from 75KGS to 25000KGS
Application: Used by various types of boats
Certificate:ABS,LR,NK,DNV,GL,RIS,BV,KR, CCS
Specification
| Weight/Mass (KG) | Size(mm) |
| A | B | C | D | E | F | G | J |
| 56KGS | 612 | 298 | 376 | 555 | 109 | 170 | 115 | 24 |
| 100KGS | 745 | 364 | 458 | 675 | 130 | 200 | 130 | 28 |
| 180KGS | 909 | 442 | 558 | 822 | 162 | 252 | 160 | 36 |
| 300KGS | 1075 | 524 | 660 | 975 | 194 | 298 | 192 | 45 |
| 428KGS | 1213 | 590 | 745 | 1098 | 215 | 336 | 215 | 48 |
| 675KGS | 1410 | 690 | 868 | 1278 | 250 | 390 | 255 | 60 |
| 750KGS | 1450 | 700 | 878 | 1315 | 256 | 396 | 255 | 60 |
| 910KGS | 1560 | 760 | 957 | 1410 | 273 | 430 | 255 | 60 |
| 970KGS | 1592 | 775 | 978 | 1445 | 284 | 440 | 280 | 62 |
| 1080KGS | 1650 | 805 | 1014 | 1495 | 294 | 455 | 280 | 62 |
| 1305KGS | 1760 | 858 | 1082 | 1595 | 313 | 485 | 310 | 68 |
| 1440KGS | 1818 | 885 | 1118 | 1645 | 324 | 505 | 310 | 68 |
| 1710KGS | 1925 | 940 | 1184 | 1745 | 343 | 532 | 340 | 74 |
| 1845KGS | 1975 | 965 | 1215 | 1785 | 347 | 546 | 340 | 74 |
| 2100KGS | 2065 | 1005 | 1268 | 1865 | 354 | 570 | 380 | 82 |
| 2475KGS | 2175 | 1062 | 1340 | 1970 | 385 | 605 | 385 | 82 |
| 2835KGS | 2265 | 1105 | 1393 | 2055 | 399 | 625 | 410 | 90 |
| 3550KGS | 2455 | 198 | 1508 | 2225 | 438 | 680 | 415 | 100 |
| 3940KGS | 2540 | 1240 | 1562 | 2300 | 453 | 705 | 450 | 100 |
| 4500KGS | 2655 | 1295 | 1632 | 2405 | 473 | 735 | 450 | 100 |
| 4840KGS | 2720 | 1330 | 1670 | 2465 | 490 | 755 | 480 | 110 |
| 4610KGS | 2858 | 1396 | 1758 | 2590 | 509 | 790 | 500 | 110 |
| 6000KGS | 2922 | 1426 | 1796 | 2646 | 515 | 810 | 500 | 110 |
| 6900KGS | 3062 | 1496 | 1884 | 2775 | 545 | 848 | 540 | 117 |
| 7800KGS | 3190 | 1558 | 1962 | 2890 | 569 | 884 | 600 | 130 |
| 8300KGS | 3256 | 1590 | 2002 | 2950 | 574 | 902 | 600 | 130 |
| 9300KGS | 3382 | 1652 | 2080 | 3064 | 606 | 936 | 630 | 135 |
| 9900KGS | 3452 | 1686 | 2124 | 3128 | 616 | 956 | 640 | 140 |
| 10575KGS | 3523 | 1720 | 2166 | 3192 | 628 | 976 | 660 | 145 |
| 11100KGS | 3589 | 1720 | 2166 | 3192 | 628 | 976 | 660 | 145 |
| 11700KGS | 3650 | 1782 | 2245 | 3308 | 648 | 1010 | 680 | 150 |
| 12300KGS | 3683 | 1794 | 2260 | 3330 | 655 | 1018 | 700 | 155 |
| 12900KGS | 3772 | 1842 | 2320 | 3418 | 670 | 1044 | 700 | 155 |
| 13500KGS | 3830 | 1870 | 2355 | 3470 | 682 | 1060 | 730 | 160 |
| 14100KGS | 3885 | 1896 | 2389 | 3520 | 689 | 1076 | 730 | 160 |
| 14700KGS | 3940 | 1924 | 2423 | 3570 | 700 | 1090 | 730 | 160 |
| 15400KGS | 4002 | 1954 | 2461 | 3626 | 710 | 1108 | 730 | 160 |
| 16100KGS | 4062 | 1982 | 2498 | 3680 | 721 | 1125 | 770 | 170 |
| 16900KGS | 4128 | 2016 | 2538 | 3740 | 721 | 1144 | 700 | 170 |
| 17800KGS | 4200 | 2050 | 2583 | 3806 | 725 | 1162 | 800 | 180 |
| 18800KGS | 4277 | 2088 | 2630 | 3875 | 729 | 1185 | 800 | 180 |
| 20000KGS | 4350 | 2101 | 2694 | 3945 | 729 | 1185 | 820 | 199 |
| 25000KGS | 5046 | 2437 | 3125 | 4577 | 846 | 1375 | 848 | 230 |
Weitong Marine can supply about 20 types of marine anchors, including Stockless Anchor, HHP anchor, marine stock anchor, yacht anchor, and offshore anchor etc., details as bellow:
| 1 | JIS stockless anchor with weight from 50kg to 29000kgs |
| 2 | Type A, B and C Hall anchor with weight from 50kg to 8300kgs |
| 3 | U. S.N stockless anchor with weight from 45kg to 13608kgs |
| 4 | Light weight anchor from 23kgs to 6804kgs |
| 5 | JIS stock anchor weight from 150kgs to 4500kgs |
| 6 | Admiralty anchor from 50kg to 5000kgs |
| 7 | High Holding Power(HHP) Matrosol Anchor from 25kgs to 1500kgs |
| 8 | Speck anchor from 100kgs to 18800kgs |
| 9 | M type SPEK anchor from 80kgs to 20000kgs |
| 10 | AC-14 HHP stockless anchor from 56kgs to 20000kgs |
| 11 | Danforth High Holding Power(HHP) anchor from 20kgs to 6000kgs |
| 12 | Welding type high holding power(HHP) stockless anchor from 12kgs to 15400kgs |
| 13 | BALDT stockless anchor from 23kgs to 15876kgs |
| 14 | AR6 and BR6 anchor from 50kgs to 15400kgs |
About US
Weitong Marine focus on developing and offering the most competetive marine products for worldwide clients with best service:
1. Quality Assurance & Inspection
We guarantee the quality,not just because we have a complete rigorous management, production and inspection processes to control the quality and avoid detail mistake, but also we attach much importance to customers’ satisfactory of product quality. What’s more, Mill Test Certificate can be provided for general products, and most of our products are approved by CCS, ABS, DNV, BV, NKK, KR, LR, GL, RINA etc.
2. Efficiency
Your request is promised to be reponsed within1-12 hours. Our experienced sales team get technical support from our engineer team to ensure swift offer and good communication.
3. On Time Delivery
We have rigorous production schedule and professional follow-up process to control the production time. Clients will be informed about the production process in time. Besides, we cooperate with reliable logistic partners to assure the goods to be delivered to you punctually.
4. Customization
If you need customization service, our experienced engineers are able to design the product as per your request or application.
5. Product Range
All marine equipment, accessories and technique solution can be offered.
6. After sales service
After shipping, we keep tracking the shipment, and once goods arrived, we will positively contact client for feedback.
We always insist on the values of “customer-oriented, always with integrity” in global trading business. Whenever you need inquiry or help, you can turn to Weitong Marine over the phone, by email or other.
Should you have any comment or inquiry, please feel free to contact us for more details
kate Yang
Tel: +86-756-8169003
Phone: +86-13923317268
sales@weitongmarine.com
Skype: katelp65
Ohter Product Photos
