Forged Weldless Round Ring
Alloy steel forged round ring is a kind of most common links. It has the advantages of small volume, light weight and high strength. And it can be widely used in Lifting and connecting, Wire rope fittings, Chain fittings, Marine hardware fittings.
It's forged supper alloy steel-quenched and temperated.
* Material: Stainless Steel, Alloy Steel.
* Surface finish: Red Ral3020/Yellow Pal1003
Special specifications and marks can be made according to customers requirments
WLL: 0.5T-150T round ring / 6 times WLL or 4 times WLL
| SIZE | WEIGHT(kg) | WLL(lbs) | B.L(lbs) |
| 3/8x2'' | 0.11 | 1100 | 6600 |
| 1/2x2'' | 0.21 | 2200 | 13200 |
| 5/8x3'' | 0.46 | 3300 | 19800 |
| 5/8x3-5/16'' | 0.5 | 3300 | 19800 |
| 3/4x3'' | 0.67 | 5000 | 30000 |
| 3/4x4'' | 0.84 | 5600 | 33600 |
| 7/8x4'' | 1.2 | 7200 | 43200 |
| 7/8x5-1/2'' | 1.55 | 5600 | 33600 |
| 1x4'' | 1.59 | 10800 | 64800 |
| 1x5-1/2'' | 2.1 | 10800 | 64800 |
| 1-1/8x6'' | 2.87 | 10400 | 62400 |
| 1-1/4x5'' | 3.1 | 17000 | 102000 |
| 1-1/4x6'' | 3.6 | 17000 | 102000 |
| 1-1/4x10'' | 5.6 | 17000 | 102000 |
| 1-3/8x6'' | 4.5 | 19000 | 114000 |
| 1-1/2x8'' | 6.8 | 25000 | 150000 |
| 1-1/2x8-3/4'' | 7.32 | 25000 | 150000 |
| 1-1/2x10'' | 8.22 | 25000 | 150000 |
| 2x12'' | 17.8 | 35000 | 210000 |
